Honda XR 500-600-650 (1979-2020): Service and Repair Manuals

Honda XL 500, XL 600 / XR 500, XR 600 (1979-1990) | Clymer Service and Repair Manual

Clymer Manual for maintenance and repair of the Honda motorcycles:
- XL500S (1979-1981), XL500R (1982), XL600R (1983-1987)
- XR500 (1979-1980), XR500R (1981-1984) and XR600R (1985-1990).

This Clymer workshop manual on Honda XL500S, XL500R, XR500, XR500R, XL600R and XR600R off-road motorcycles describes maintenance and repair of the engine, clutch and gearbox, the fuel and exhaust systems, the electrical system and the cooling system.
Also covers the front suspension and steering system, the rear suspension and drivetrain, the brakes and the frame.

• Step-by-step instructions, many photos and drawings.
• Includes adjustment data, torque wrench settings and troubleshooting tables.
• Clear wiring diagrams in colour.

Information

Details:	424 pages, 25.5 x 18 x 2 cm / 10 x 7.1 x 0.79 in, paperback
Illustrations:	numerous photos and drawings
Publisher:	Clymer (USA, 2007)
Series:	Clymer Motorcycle Service and Repair Manual (M339-8)
ISBN:	9781599691428

More information on the Clymer Repair Manuals

Honda XL 250, XL 500 / XR 250, XR 500 (1978-1984) | Haynes Owners Workshop Manual

Haynes Owners Workshop Manual on the Honda motorcycles:
- XL250S (248 cc, 1978-1982), XL250S (248 cc, 1978-1981, USA), XL250R (248 cc, 1982-1984), XL250R (248 cc, 1981-1982, USA)
- XL500S (490 cc, 1979-1982), XL500S (490 cc, 1979-1981, USA), XL500R (490 cc, 1982-1984), XL500R (490 cc, 1982, USA)
- XR250 (248 cc, 1979-1980), XR250R (248 cc, 1981-1982, USA)
- XR500 (490 cc, 1979-1980), XR500R (490 cc, 1981-1982, USA).

Exclusions: This manual does not cover the RFVC engines.

This Haynes manual on the Honda XL 250, XL 500, XR 250 and XR 500 off-road motorcycles provides photos and detailed step-by-step instructions for maintenance and repair of the engine, the clutch and the gearbox.
The cooling system, fuel system, ignition, exhaust, steering, suspension, brakes, final drive and electrical system are also described.

• Based on a complete strip-down and rebuild.
• Includes a maintenance schedule, adjustment data, torque wrench settings and troubleshooting tables.
• Clear and detailed wiring diagrams for easy reference.

Information

Author:	Pete Shoemark
Details:	192 pages, 27 x 21.5 x 1.2 cm / 10.6 x 8.5 x 0.47 in, paperback
Illustrations:	hundreds of photos and drawings
Publisher:	Haynes Publishing (GB, 1988)
Series:	Haynes Owners Workshop Manual (0567)
ISBN:	9781850102687

More information on the Haynes Repair Manuals

Honda XL / XR 600 R & XR 650 L/R (1983-2020) | Haynes Service & Repair Manual

Haynes Service & Repair Manual on the Honda motorcycles:
- XL600R (589 cc, 1983-1987)
- XR600R (591 cc, 1985-2000)
- XR650L (664 cc, 1993-2020)
- XR650R (649 cc, 2000-2007).

This Haynes manual on the Honda XL 600 R, XR 600 R, XR 650 L and XR 650 R offroad motorcycles provides photos and detailed step-by-step instructions for maintenance and repair of the engine, the clutch and the gearbox.
The cooling system, fuel system, ignition, exhaust, suspension, final drive and brakes are also covered.

• Based on a complete strip-down and rebuild.
• Includes a maintenance schedule, adjustment data, torque wrench settings and troubleshooting tables.
• Very clear and detailed wiring diagrams in colour for easy reference.
• Contains also a brief model history.

Information

Details:	256 pages, 27 x 21 x 1.5 cm / 10.6 x 8.25 x 0.59 in, paperback
Illustrations:	hundreds of photos and drawings
Publisher:	Haynes Publishing (GB, 2020)
Series:	Haynes Service & Repair Manual (2183)
ISBN:	9781620923962

More information on the Haynes Repair Manuals

Honda XR 650R (2000-2007) | Clymer Service and Repair Manual

Clymer Manual for maintenance and repair of the Honda motorcycles XR650R (2000-2007).

Exclusions: This manual does not cover the XR650L (see hiervoor ref. M221).

This Clymer workshop manual on Honda XR 650 R off-road motorcycles describes maintenance and repair of the engine, clutch and gearbox, the fuel and exhaust systems, the electrical system and the cooling system.
Also covers the front suspension and steering system, the rear suspension and drivetrain, the brakes and the frame.

• Step-by-step instructions, many photos and drawings.
• Includes adjustment data, torque wrench settings and troubleshooting tables.
• Clear wiring diagrams in colour.

Information

Details:	328 pages, 25.5 x 18 x 1.7 cm / 10 x 7.1 x 0.67 in, paperback
Illustrations:	numerous photos and drawings
Publisher:	Clymer (USA, 2008)
Series:	Clymer Motorcycle Service and Repair Manual (M225)
ISBN:	9781599692036

More information on the Clymer Repair Manuals

Honda XR 600R (1991-2000) & XR 650L (1993-2019) | Clymer Service and Repair Manual

Clymer Manual for maintenance and repair of the Honda motorcycles:
- XR 600R (1991-2000)
- XR 650L (1993-2019).

Exclusions: This manual does not cover the XR 650R.

This Clymer workshop manual on Honda XR 600R and XR 650L off-road motorcycles describes maintenance and repair of the engine, clutch and gearbox, the fuel and exhaust systems, the electrical system and the cooling system.
Also covers the front suspension and steering system, the rear suspension and drivetrain, the brakes and the frame.

• Step-by-step instructions, many photos and drawings.
• Includes adjustment data, torque wrench settings and troubleshooting tables.
• Clear wiring diagrams in colour.

Information

Details:	336 pages, 26 x 18 x 2 cm / 10.25 x 7.1 x 0.79 in, paperback
Illustrations:	numerous photos and drawings
Publisher:	Clymer (USA, 2020)
Series:	Clymer Motorcycle Service and Repair Manual (M221)
ISBN:	9781620923641

More information on the Clymer Repair Manuals
