Fiat Punto III (2005-2015) service & repair manuals

Fiat Grande Punto, Punto Evo & Punto - Petrol (2006-2015) | Haynes Service and Repair Manual

Haynes Repair Manual covering the Fiat Grande Punto, Punto Evo and Punto.

Petrol engines: 1.2 L (1242 cc) and 1.4 L (1368 cc).

Production years: 2006-2015.

Exclusions: This manual does not cover the TwinAir, Multiair or T-Jet petrol models, the diesel engines, the duel-fuel models, the Dualogic transmission, the Punto Classic (2006-2007), the Punto Abarth or the van versions.

This Haynes manual for the Fiat Grande Punto, Punto Evo and Punto models from the years 2006-2015 describes service and repair of the petrol engines (distribution, belts, valves, camshaft, cylinder head, oil pump, seals and radiator).
It also includes procedures for the heater, fuel system, exhaust, starting and charging system.

Additionally this DIY guide describes work on the clutch, gearbox, driveshafts, braking system, suspension, steering gear, body, interior, and electrical system.

• Step-by-step instructions with hundreds of detailed photos guide you through every job.
• Based on a complete vehicle strip-down and rebuild.
• Includes a maintenance schedule, technical specifications, torque wrench settings, and troubleshooting tables.
• Clear and detailed wiring diagrams.

Product details

More information on the Haynes Repair Manuals

Fiat Grande Punto - essence 1.4 8V et Diesel 1.3 Multijet (depuis 09/2005) | Revue Technique Automobile RTA B704.5

Revue Technique Automobile (RTA B704) repair manual covering the Fiat Grande Punto, 3 and 5-door.

Versions: 1.4, 1.3DT 16v Multijet, Active, Dynamic, Emotion, Collezione, Dolvia, orange.

Petrol engines: 1.4 8V (1368 cc).

Diesel engines: 1.3 Multijet JTD (1248 cc, 75 and 90 hp).

Production years: since 9/2005.

This Revue Technique for the Fiat Grande Punto describes extensively service and repair of the petrol and diesel engines (including timing gear, cylinder head, lubrication, coolant pump and fuel system).
Covers also work on the clutch, transmission, driveshafts, steering system, suspension, wheel hubs, brakes, electric equipment and body.

• Includes adjustment data, torque wrench settings and wiring diagrams.
• An integral owner's handbook provides information on operation and daily maintenance.
• Additional chapter with tips and a checklist to prepare for the MOT test.
• Partly in colour.

Product details

More information on the Revue Technique Automobile manuals

Fiat Punto Evo - Essence 1.4 Multiair 105 ch (depuis 10/2009) | Revue Technique Automobile RTA 007

Revue Technique Automobile (RTA 007) repair manual covering the Fiat Punto Evo petrol models.

Petrol engines: 1.4 Multiair (77 kW/105 hp, engine code 955A6000).

Production years: since 10/2009.

This Revue Technique for the Fiat Funto Evo describes extensively service and repair of the 1.4 litre petrol engine (including timing gear, cylinder head, lubrication, coolant pump and fuel system).

This RTA repair manual also covers work on the clutch, transmission, driveshafts, steering system, suspension, wheel hubs, brakes, electric equipment and body.

• Includes adjustment data, torque wrench settings and wiring diagrams.
• An integral owner's handbook provides information on operation and daily maintenance.
• Additional chapter with tips and a checklist to prepare for the MOT test.

Product details

More information on the Revue Technique Automobile manuals

Fiat Grande Punto - benzyna i diesel (2005-2009)

A richly illustrated professional guide to the construction, operation and repair of individual mechanisms and assemblies of Fiat Grande Punto cars manufactured from 2005 to 2009.

Petrol engines:
- 1.2 8V with 65 HP
- 1.4 8V with 77 HP
- 1.4 16V with 95 HP
- 1.4 16V T-Jet with turbocharging 120 HP

Diesel engines:
- 1.3 Multijet 75 HP and 90 HP
- 1.9 Multijet 120 HP
- 1.9 Multijet SPORT 130 HP

With mechanical gearboxes.

• Detailed technical and adjustment data, technical maintenance principles, necessary consumables.
• Description of disassembly, repair and assembly of individual parts, mechanisms and assemblies, and electrical wiring diagrams.

Product details
