BMW 5-series (E34, 1989-1991): Service and Repair Manuals

A repair manual on your BMW 5-Series (E34, 1989-1991)? Explore here workshop manuals for service and repair of BMW cars. They provide detailed instructions for troubleshooting and parts replacement.

BMW 3-Series - Petrol (E30, 1981-1991) & 5-Series - Petrol (E28 and E34, 1983-Apr 1991) | Haynes Service and Repair Manual

Haynes workshop manual on the BMW 3-Series (E30) and 5-Series (E28 and E34), including Touring and Cabriolet.

Models:
- 316 (1983-1988), 316i (1988-1991), 318i (1983-1991), 320i (1987-1991), 325i (1987-1991)
- 518 (1981-1985), 518i (1985-1991), 520i (1988-1991), 525i (1981-1991), 528i (1981-1988), 530i (1988-1991), 535i (1985-1991) and M535i (1985-1988).

Petrol engines:
- 4 cylinders - 1.6 L (1596 cc, SOHC, engine code M40), 1.8 L (1766 cc, SOHC, M10), 1.8 L (1796 cc, SOHC, M40)
- 6 cylinders - 2.0 L (1990 cc, SOHC, M20), 2.5 L (2494 cc, SOHC, M20 and M30), 2.8 L (2788 cc, SOHC, M30), 3.0 L (2986 cc, SOHC, M30) and 3.5 L (3430 cc, SOHC, M30).

Exclusions: This manual does not cover the DOHC petrol engines, the diesel engines, the V8 or the 4x4 drive.

Pages of the book BMW 3- & 5-Series (sohc) (83-91/81-91) (1)

This Haynes manual for the BMW 3-Series (E30) and 5-Series (E28 and E34) guides you through the maintenance and repair of the petrol engines (distribution, belts, valves, camshaft, cylinder head, oil pump, seals and radiator).
It also includes procedures for the heater, fuel system, exhaust, starting and charging system. Additionally, it covers work on the clutch, gearbox, driveshafts, braking system, suspension, steering gear, body, interior and electrical system.

  • Step-by-step instructions with detailed photos.
  • Based on a complete strip-down and rebuild.
  • Includes a maintenance schedule, technical specifications, torque wrench settings and troubleshooting tables.
  • Clear and detailed wiring diagrams.

Information

Details:256 pages, 27 x 21 x 1.5 cm / 10.6 x 8.25 x 0.59 in, paperback
Illustrations:hundreds of photos and drawings
Publisher:Haynes Publishing (GB, 2013)
Series:Haynes Service and Repair Manual (1948)
ISBN:9780857337054

More information on the Haynes Repair Manuals

BMW 3-Series - Petrol (E30, 1981-1991) & 5-Series - Petrol (E28 and E34, 1983-Apr 1991) | Haynes Service and Repair Manual

BMW 3-Series - Petrol (E30, 1981-1991) & 5-Series - Petrol (E28 and E34, 1983-Apr 1991)

Language: English

Buy from Amazon.com
Buy from Amazon UK
Buy from Amazon CA

BMW 3 & 5 Series (E30 / E28 and E34) (1982-1992) (USA) | Haynes Repair Manual

Haynes Repair Manual on the BMW 3-Series (E30) and 5-Series (E28 and E34). Beschrijft over the next versions:
- 318i (1984-1985)
- 325, 325e, 325es (1984-1988)
- 325i, 325is, 325ic (1987-1990)
- 525i (1989-1990)
- 528e (1982-1988)
- 533i (1983-1994)
- 535i, 535is (1985-1992).

Gasoline engines: 4 cylinders - 1.8 litre / 6 cylinders - 2.5, 2.7, 3.2 and 3.4 litre.

Exclusions: This manual does not cover the diesel or 4x4 models.

This Haynes manual for the BMW 3-Series (E30) and 5-Series (E28 and E34) guides you through the maintenance and repair of the gasoline engines (distribution, belts, valves, camshaft, cylinder head, oil pump, seals, and crankshaft).
It also includes procedures for the cooling, air conditioning, fuel system, exhaust plus the starting and charging system. Additionally, it covers work on the clutch, gearbox (removal and installation), propshafts, braking system, suspension, steering box, body, interior and electrical system.

  • Step-by-step instructions with detailed photos.
  • Covers U.S. and Canadian models.
  • Based on a complete strip-down and rebuild.
  • Includes a maintenance schedule, technical specifications, torque wrench settings and troubleshooting tables.
  • Clear and detailed wiring diagrams.

Information

Author:Larry Warren, J. H. Haynes
Details:256 pages, 27 x 21 x 1.4 cm / 10.6 x 8.25 x 0.55 in, paperback
Illustrations:hundreds of photos and drawings
Publisher:Haynes Manuals, Inc. (USA, 1988)
Series:Haynes Auto Repair Manual (18020)
ISBN:9781563920202

More information on the American Haynes Repair Manuals

BMW 3 & 5 Series (E30 / E28 and E34) (1982-1992) (USA) | Haynes Repair Manual

BMW 3 & 5 Series (E30 / E28 and E34) (1982-1992) (USA)

Language: English

Buy from Amazon.com
Buy from Amazon UK
Buy from Amazon CA

BMW 5 Series (E34) - 525i, 530i, 535i, 540i, including Touring (1989-1995) (USA) - Bentley Service Manual

Bentley Service Manual covering in great detail maintenance and repair of the BMW 5-Series (E34).

Versions:
- 525i (1989-1995)
- 530i (1994-1995)
- 535i (1989-1993)
- 540i (1994-1995)
- Including the Touring models.

Gasoline engines:
- 2.5 L (M20 with DME 1.3)
- 2.5 L (M50 with DME 3.1
- 2.5 L (M50TU/Vanos with DME 3.3.1)
- 3.0 L (M60 with DME 3.3)
- 3.5 L (M30 with DME 1.3)
- 4.0 L (M60 with DME 3.3).

Manual gearboxes (removal and installation, external service):
- Getrag 260/5 and 260/6
- Getrag S5D 250G
- Getrag S6S 560G

Automatic transmissions (removal and installation, external service):
- ZF 4HP22/EH
- ZF A4S 310R (THM-R1)
- ZF A5S 310Z
- ZF A5S 560Z.

Model years: 1989-1995.

This Bentley workshop manual on the BMW 5-Series (E34) provides detailed instructions for work on the engines (mechanical part, distribution, valves, ignition, starter, alternator) and cooling system.
Covers also the clutch, transmission (only removal and installation), suspension, brakes, steering, fuel system, exhaust, electrical system, interior, doors, central locking and air conditioning.

  • Covers U.S. and Canadian models.
  • Complete with adjustment data, torque wrench settings, OBD fault codes and wiring diagrams.
  • This is the most comprehensive workshop manual available for these cars.

Information

Details:672 pages, 28.5 x 22 x 4 cm / 11.2 x 8.7 x 1.57 in, hardback
Illustrations:926 photos and drawings
Publisher:Bentley Publishers (USA, 2012)
Series:Bentley Service Manual
ISBN:9780837616971

More information on the Bentley Service Manuals

BMW 5 Series (E34) - 525i, 530i, 535i, 540i, including Touring (1989-1995) (USA) - Bentley Service Manual

BMW 5 Series (E34) - 525i, 530i, 535i, 540i, including Touring (1989-1995) (USA) - Bentley Service Manual

Language: English

Buy from Amazon.com
Buy from Amazon UK
Buy from Amazon CA

BMW 5 & 6 Series (E12, E24, E28, E34) - Restoration Tips & Techniques

Brooklands restoration manual for the BMW 5 and 6-Series models from the years 1972-1995 (Series E12, E24, E28 and E34), including the Alpina, M5 and M6.
Gives also purchase tips and information about the model history and identification.

  • This manual describes the complete restoration of the BMW E12, E24, E28 and E34 models: body (including the replacement of bonnet, fenders, windows, doors and bumpers), interior (seat cover, dashboard and door panels), engine (removal and installation, overhaul), chassis (clutch, gearbox, suspension, brakes, steering), electrical installation (lamps, dynamo, starter motor, windscreen wipers).
  • Richly illustrated and clear step-by-step instructions.
  • Also troubleshooting tables and overview with specifications on a year-by-year basis.

Information

Author:Andrew Everett
Details:236 pages, 27 x 19.5 x 1.5 cm / 10.6 x 7.7 x 0.59 in, paperback
Illustrations:numerous b&w and colour photos
Publisher:Brooklands Books (GB, 2012)
ISBN:9781855209626
BMW 5 & 6 Series (E12, E24, E28, E34) - Restoration Tips & Techniques

BMW 5 & 6 Series (E12, E24, E28, E34) - Restoration Tips & Techniques

Language: English

Buy from Amazon.com
Buy from Amazon UK
Buy from Amazon CA

BMW série 5 (E34): 520i, 525i, 524td - moteurs essence 2.0-2.5 (12 et 24 soupapes) et turbo Diesel 2.4 (1989-1991) | Revue Technique Automobile RTA 521.2

Revue Technique Automobile (RTA 521) covering the BMW 5-Series (E34).

Versions: 520i, 525i and 524td.

Petrol engines:
- 1990 cc (M20 B20 and M50 B20, 12 and 24 valves)
- 2494 cc (M20 B25 and M50 B25, 12 and 24 valves).

Diesel engines: 2443 cc turbo (M21).

Production years: 1989-1991.

This Revue Technique for the BMW 520i, 525i and 524td (E34) describes extensively service and repair of the petrol and diesel engines (including timing gear, cylinder head, lubrication, coolant pump and fuel system).
Covers also work on the clutch, transmission, driveshafts, steering system, suspension, wheel hubs, brakes, electric equipment and body.

  • Includes adjustment data and wiring diagrams.
  • An integral owner's handbook provides information on operation and daily maintenance.
  • Additional chapter with tips and a checklist to prepare for the MOT test.

Information

Details:144 pages, 27 x 21 cm / 10.6 x 8.25 in, paperback
Illustrations:hundreds of photos and drawings
Publisher:ETAI (F, )
Series:Revue Technique Automobile (RTA 521.2)
ISBN:9782726852125

More information on the Revue Technique Automobile manuals

BMW série 5 (E34): 520i, 525i, 524td - moteurs essence 2.0-2.5 (12 et 24 soupapes) et turbo Diesel 2.4 (1989-1991) | Revue Technique Automobile RTA 521.2

BMW série 5 (E34): 520i, 525i, 524td - moteurs essence 2.0-2.5 (12 et 24 soupapes) et turbo Diesel 2.4 (1989-1991)

Language: French

Buy from Amazon.com
Buy from Amazon UK
Buy from Amazon CA

BMW 5er Reihe (E34) - Benziner und Diesel - Limousine (9/1987-7/1995), Touring (9/1991-1/1996) | So wird's gemacht

Workshop manual from the German Series So wird's gemacht (nr. 67) on the BMW 5-Series (E34), petrol and diesel.

Petrol engines:
.518i:
- 1.8 L (83 kW/113 hp, engine code M40 01/93-08/94)
- 1.8 L (85 kW/115 hp, M43 09/94-01/96)
.520i:
- 2.0 L (95 kW/129 hp, M20 09/87-04/90)
- 2.0 L (110 kW/150 hp, M50 05/90-01/96)
.525i:
- 2.5 L (125 kW/170 hp, M20 09/87-04/90)
- 2.5 L (141 kW/192 hp, M50 05/90-01/96)
.530i:
- 3.0 L (138 kW/188 hp, M30 09/87-08/90)
.535i:
- 3.5 L (155 kW/211 hp, M30 09/87-08/92)

Diesel engines:
524Td:
- 2.4 L (85 kW/115 hp, M21 09/87-08/90)
525Td:
- 2.5 L (85 kW/115 hp, M51 04/93-01/96)
525Tds:
- 2.5 L (105 kW/143 hp, M51 09/90-01/96)

Production years:
- Limousine 09/1987-07/1995
- Touring 09/1991-01/1996.

The initial section of this manual on the BMW 5-Series (E34) covers inspection and daily maintenance of the petrol and diesel engines, transmission, brakes, steering and body (including the electrical system, windscreen wipers, lighting and heating or air conditioning).

Furthermore, this book provides detailed guidance on the following components:
- Suspension (replacement of driveshafts, springs and shock absorbers), steering (ball joints) and brakes (discs, brake linings and handbrake).
- Electrical system (battery, voltage regulator and starter motor).
- Dismantling and assembly of the engine cylinder head and cam drive, including replacement of the v-belt and the timing belt or chain.
- The lubricating system with the oil pump.
- The cooling system (replacement of radiator, thermostat and cooling fan).
- The fuel system (air filter, fuel pump and fuel filter) and exhaust (replacement of mufflers).
- Interior: removal and refitting of the dashboard, instrument panel, consoles, interior trim and seats.
- Body: dismantling and assembly of bumpers, fenders, bonnet, tailgate, doors, window mechanisms, locks and mirrors.

  • Extensive technical specifications, adjustment data and torque wrench settings.
  • Clear wiring diagrams of the main circuits.

Information

Author:Rüdiger Etzold
Details:314 pages, 26 x 19.5 cm / 10.25 x 7.7 in, paperback
Illustrations:570 photos and drawings
Publisher:Delius Klasing Verlag GmbH (D, 2019)
Series:So wird's gemacht (67)
ISBN:9783768806510

More information on the series So wird's gemacht

BMW 5er Reihe (E34) - Benziner und Diesel - Limousine (9/1987-7/1995), Touring (9/1991-1/1996) | So wird's gemacht

BMW 5er Reihe (E34) - Benziner und Diesel - Limousine (9/1987-7/1995), Touring (9/1991-1/1996)

Language: German

Buy from Amazon.com
Buy from Amazon UK
Buy from Amazon CA

BMW 520i, 525i, 530i, 535i - Sechszylinder (E34) (ab 1/1988) | Jetzt helfe ich mir selbst

Repair manual from the Series "Jetzt helfe ich mir selbst" (nr. 141, reprint) for the BMW 520i, 525i, 530i and 535i (Series E34).

Petrol engines:
- 2.0 L (12V - 95 kW/129 hp, 24V - 110 kW/150 hp)
- 2.5 L (12V - 125 kW/170 hp, 24V - 141 kW/192 hp)
- 3.0 L (138 kW/188 hp)
- 3.5 L (155 kW/211 hp).

Production years: since 1/1988.

Pages of the book [JH 141] BMW 520i-535i - 6-Zyl (E34) (ab 1/1988) (1)

  • This repair manual on the BMW 520i, 525i, 530i and 535i describes maintenance and repair of the 6-cylinder petrol engines: the lubricating system, cooling, fuel system, filters and exhaust.
  • Covers also the clutch and transmission, the suspension, the steering system, the servo unit and the brakes, the electrical system (including windscreen wipers and lighting), the interior and the body.
  • This manual contains also adjustment data and a maintenance schedule.

Information

Author:Dieter Korp
Details:286 pages, 26.5 x 20 cm / 10.4 x 7.9 in, paperback
Illustrations:numerous photos and drawings
Publisher:Motorbuch Verlag (D, 1999)
Series:Jetzt helfe ich mir selbst (141)
ISBN:9783613013469

More information on the series Jetzt helfe ich mir selbst

BMW 520i, 525i, 530i, 535i - Sechszylinder (E34) (ab 1/1988) | Jetzt helfe ich mir selbst

BMW 520i, 525i, 530i, 535i - Sechszylinder (E34) (ab 1/1988)

Language: German

Buy from Amazon.com
Buy from Amazon UK
Buy from Amazon CA

BMW 5er-Reihe - 520i, 525i, 530i, 535i - Sechszylinder (ab 1/1988) | Bucheli Reparaturanleitung

Bucheli Reparaturanleitung for service and repair of the BMW 520i, 525i, 530i and 535i (Series E34).

Petrol engines: 6 cylinders - 2.0 L (129 hp), 2.5 L (170 hp), 3.0 L (183 hp) and 3.5 L (211 hp).

Production years: since 1/1988.

Pages of the book [0967] BMW 5er-Reihe - Sechszylinder (ab 1/88) (1)

This Bucheli manual on the BMW 520i, 525i, 530i and 535i provides detailed instructions for work on the 6-cylinder petrol engines (removal - refitting, crankshaft, connecting rods, pistons, distribution, valves, oil pump, cooling, fuel system).
Covers also the clutch, gearbox (only removal and installation), driveshafts, steering system, front and rear suspension, brakes, electrical system and the exhaust.

  • Includes comprehensive technical data and torque wrench settings.
  • Clear wiring diagrams.

Information

Details:143 pages, 28 x 21 cm / 11 x 8.25 in, paperback
Illustrations:numerous photos and drawings
Publisher:Bucheli Verlag (CH, 1999)
Series:Bucheli Reparaturanleitung (967-969)
ISBN:9783716817636

More information on the Bucheli repair manuals

BMW 5er-Reihe - 520i, 525i, 530i, 535i - Sechszylinder (ab 1/1988) | Bucheli Reparaturanleitung

BMW 5er-Reihe - 520i, 525i, 530i, 535i - Sechszylinder (ab 1/1988)

Language: German

Buy from Amazon.com
Buy from Amazon UK
Buy from Amazon CA

Related titles:

BMW 5-Series - 6-cylinder Petrol (4/96-8/03)

BMW 5-Series (E39) - 6-cylinder Petrol (Apr 1996 - Aug 2003)

Peter Gill, Andy Legg | English | paperback | 272 p. | 2015

[SW 102] BMW 5er Reihe (E39) (12/1995-6/2003)

BMW 5er Reihe (E39) - Benziner und Diesel (12/1995-6/2003)

Rüdiger Etzold | German | paperback | 316 p. | 2019

[RTA 594.2] BMW 525 tds (E39) (1996-2000)

BMW 525 tds Diesel (E39) (1996-2000)

French | paperback | 122 p.

[JH 205] BMW 5er-Reihe (9/1995-2004)

BMW 5er-Reihe (E39) - Benzin- und Dieselmotoren (9/1995-2004)

Friedrich Schröder | German | paperback | 268 p. | 2014

BMW serii 5 (typu E39, od 12/1995 do 06/2003)

BMW serii 5 - benzyna i diesel (typu E39, 12/1995 - 06/2003)

Hans-Rüdiger Etzold | Polish | paperback | 356 p. | 2009

< Top >

The TMB Bookshop presents not only technical books on BMW . Click here to discover all books on BMW (including make histories, type overviews, books about certain models, road test collections, etc.).

Years: 1989 1990 1991


Last update: 2024-12-16
